5KW High Generation Solar Power System-Anern

5KW High Generation Solar Power System

by Anern

Description:

The MPSG-T-D5000 5kw plus solar energy storage system is the latest touch screen MPPT portable solar generator. Double CPU intelligent control technology, performance excellence,the solar storage system status would be shown in the mobile phone APP or webpage of computer by Wi-Fi module(optional),it is the best flexible power station to meet various scenarios, like
kitchen, living room, study, backyard and work station ect..

Package Content:

1pcs MPPT Portable Solar Generator(5Kw), Solar Panel Bracket, Cables, (1pcs Wifi Monitoring Module-Optional)

The shipping cost and product prices are for reference only, pls leave your demands and contact information, we will send you the quotation soon.

For wholesale business or project, pls email: Cooperation@anern.com

Save $157.00 Save $157.00
$3,542.00
$3,542.00 - $3,542.00
$3,542.00
$3,385.00
$3,385.00 - $3,385.00
$3,385.00

Video of 5KW High Generation Solar System




Specification of 5KW High Generation Solar System

Model

MPSG-T-D5000

Battery Voltage

48V

Inverter



RATED POWER

5000W

Input Voltage Range

170-275VAC

Input Frequency

45-65

Output Voltage

110/220

Output Frequency

50/60

Output Wave

Pure Sine Wave

Speficifation Of Built-in Lithium Battery

9000WH(Double battery box)

Communication

WIFI(optional)

MPPT Solar Input



Max. PV Power

3000W

Range Of Charging Voltage

65-150VDC

Rated Charge Current

60A(MPPT)

MPPT efficiency



Voltage For Floating Charge

49.8VDC

Low Voltage Recovery Voltage

46.8VDC

Low Voltage Protecton Voltage

37.2VDC

DC Output



Mobile output

TYPE C-PD60 / USB QC3.0 / USB-5VDC 2.4A/2 units

12VDC Output Ports

2 units /MAX 2A

PHYSICAL



Heat Dissipation/Cooling

Temperature control by intelligent exhaust fan

Display

Touch Screen

External Size：W*D*H（mm）

536*480*735mm

Package Size：W*D*H（mm）

660*600*840mm

G.W.(Gross Weight)

120





★★★★★
★★★★★
★★★★★
★★★★★
