215KWH Commercial ESS Lithium-ion Battery Storage

Description:

Battery module(Wh/V): 14.336kWh, 51.2V
Number of modules: 15
Cell technology: LFP (LiFePO4)
Battery usable energy: 215.04kWh
Nominal voltage: 768V
Operating voltage: 672-876V
Standard charging & discharging: 140A/0.5C
Maximum continuous charging & discharging: 140A/0.5C
Display: SOC status indication, Alarm indication, LCD display
Communication: CAN / RS485
Dimension (W*D*H)(mm): 1120(W)*845(D)*2100(H) mm
Weight Approximate (kg): 1920kg
Discharging temperature range: -30~55℃
Charging temperature range: -10～45℃
Protection rating: IP20
