Portable solar lives on tight margins. Currents are modest, components are compact, and the power source changes with the sun. That makes short-circuit protection and overcurrent protection a design task, not a checkbox. You need devices that trip fast on a fault, yet hold through inrush and normal peaks. You also need coordination across DC and AC sides so a small fault does not take down the whole kit.
Converter-based systems limit fault current by design. That improves semiconductor survival but makes fault detection harder. As noted in Integrating Solar and Wind, short-circuit current from power electronic resources is constrained, so protection needs adjustment compared with legacy grids. Grid Codes for Renewable Powered Systems also points out that grid-forming units may need higher ratings to support short-circuit current and fast events, while most solar inverters cannot deliver large overcurrent for long. These realities shape every device choice you make.
Fault-current reality in portable PV+ESS
PV array contribution
PV modules have a short-circuit current Isc near their nameplate at standard test conditions. In bright, cool conditions, Isc can rise modestly. Many codes use 1.25× to 1.56× multipliers for OCPD and conductor sizing to cover irradiance and manufacturing tolerance. This margin helps your short-circuit protection open under the worst case. The array current scales with the number of parallel strings, while series strings raise voltage for the same current. For two strings in parallel, backfeed into a single string during a fault is limited; with three or more strings, dedicated string fuses become critical to stop cross-string fault energy.
Battery and inverter contribution
LiFePO4 batteries can deliver high peak current, but the BMS often trips fast and clamps the event. Many portable packs will cut off within 1–3 ms in a short, limiting let-through energy. Inverters typically limit current to 1.1–2.0× rated output for a short time to protect semiconductors. As summarized in Grid Codes for Renewable Powered Systems, converter hardware constrains fault current, which reduces protection margins and calls for careful coordination. The upshot: your DC protection must interrupt low to moderate fault currents reliably, and your AC protection should not expect the multi-kiloamp surges seen from synchronous sources.
Device selection and circuit breaker design
String and battery fusing basics
Use gPV fuses on PV strings or at the array combiner. Size them above the string’s operating current but below the cable ampacity and device max. Match DC voltage rating to the array maximum voltage with margin. Place a main DC fuse or breaker close to the battery. Pick a device with enough DC breaking capacity to clear the worst-case battery short within the BMS trip window. Keep conductor lengths short to reduce loop inductance and arcing.
DC breakers vs fuses for portable solar
DC arcs are persistent. The device must extinguish the arc at low voltage and low fault current. Not all AC breakers can do this. Use DC-rated devices only. Solid-state current limiters can slash let-through energy, but they add cost and losses. The table compares common options for portable solar power systems.
| Device type | Typical DC voltage rating | Typical breaking capacity | Trip speed | Pros | Caveats |
|---|---|---|---|---|---|
| gPV fuse (10–32 A) | 600–1000 V DC | 10–50 kA | ms to sub-ms | High DC interruption; simple; polarity agnostic | One-shot; needs holders; verify I2t vs cable |
| DC MCB (1–63 A) | 60–250 V DC per pole | 2–10 kA | tens of ms | Resettable; compact; field-friendly | Polarity and series-pole rules; slower than fuses |
| DC MCCB (63–250 A) | 250–600 V DC | 10–25 kA | tens of ms | Adjustable trip; higher capacity | Bulk; weight; cost |
| Solid-state limiter | 12–60 V DC | Designed to limit, not interrupt | µs to ms | Very low let-through energy; fast | Heat dissipation; price; often needs series fuse |
Design for selectivity. Downstream devices should trip first. Upstream devices should hold for short, smaller downstream faults. Floating offshore wind outlook discusses DC protection zones with fast breakers in HVDC. The principle applies even at low voltage: divide the system into zones so a string fault does not drop the battery bus.
Coordination: make curves work for you
Three-step sizing method
- Estimate available fault current on each segment. PV: use 1.25× Isc per string, add strings in parallel. Battery: use BMS short-circuit spec and cable limits. Inverter DC input: use rated DC current and any surge factor.
- Pick OCPDs with trip curves that clear faults faster than cable damage time. Keep upstream devices outside the fast portion of their curves for selective grading.
- Verify voltage and breaking capacity margins. Account for arcing at 12–48 V DC and ensure devices are listed for the exact voltage and polarity scheme.
Worked example: 24 V portable kit
Scenario: two folding 200 W panels in parallel (Isc per panel 10 A), 24 V MPPT, 24 V 100 Ah LiFePO4 battery with BMS short-circuit cutoff in 2 ms at 400 A peak, 1.5 kW inverter with 2× current limit for 10 ms, 6 mm² DC cables up to 2 m.
| Segment | Fault current estimate | OCPD type and rating | Target trip | Notes |
|---|---|---|---|---|
| Each PV string | 1.25 × 10 A ≈ 12.5 A | gPV fuse 15 A, ≥250 V DC | Fast blow on backfeed | With two strings, fusing is often optional; assess backfeed and controller limits |
| Array combiner output | ~25 A from sun, low short capability | DC MCB 32 A, ≥60 V DC | Delay to avoid nuisance | Used as disconnect and overcurrent backup |
| Battery main | Up to BMS limit ~400 A for 2 ms | DC MCCB 125 A, ≥60 V DC, ≥5 kA | Instant curve region | Place within 15 cm of battery; cable ampacity ≥125 A |
| Inverter DC input | ~70 A rated, surge ~140 A | DC MCB 100 A or fuse 100 A | Hold through 10 ms surge | Coordinate above inverter surge but below cable ampacity |
| Aux DC loads (12 V via buck) | Converter limited, e.g., 20–30 A | MCB 25 A, 60 V DC | Type C curve | Short, fused leads near the step-down module |
Check your cables against let-through energy. Thermal damage time for 6 mm² copper under 400 A is very short. Fast devices and short leads shrink the risk. For AC output, coordinate RCD/GFCI and MCBs so leakage protection trips on ground faults while overcurrent protection handles overloads. Keep nuisance trips low by grading settings across devices, as also discussed in utility-scale practice in System Integration of Renewables.
Mode transitions and portable microgrids
Portable kits often dock into a site microgrid. Settings may need to change between islanded and grid-connected modes. Quality infrastructure for smart mini-grids highlights that protection values, power flow, neutral earthing, and short-circuit levels shift during transitions. It references active work such as IEEE P2030.12 and IEC TS 62898-1 for protective device coordination across modes. For resilience, grid-forming inverters can support autonomous restoration. A field test reported in Success Story—Using Renewable Microgrids to Keep the Lights On used 24 grid-forming inverters to blackstart and resynchronize microgrids despite short circuits. Even so, fault currents remained limited, so protection relied on fast, selective devices rather than brute current.
Build for the field
Environmental and mechanical details
- Use IP-rated enclosures and connectors. Water and dust raise fault risk. Strain-relieve every movable lead.
- Polarity keys and shrouded terminals prevent accidental shorts. Cover battery studs.
- Thermal management matters. High temperature shifts trip curves and cable ampacity.
Testing and maintenance
- Do an insulation resistance test on DC harnesses at a safe test voltage.
- Measure loop impedance on the AC side to confirm breaker clearance times.
- Use a clamp meter to capture inrush and short peaks during controlled tests.
- Scan with a thermal camera under full load to spot hot spots at lugs and breakers.
As noted in Integrating Solar and Wind, the rise of converter-dominated systems broadens voltage fluctuation and reduces fault current. Your portable design counters this with selective zoning, DC-rated interruption, and clear settings. Borrow the zoning mindset from HVDC protection (Floating offshore wind outlook) and the multi-layer control perspective from the DOE project (Success Story—Using Renewable Microgrids to Keep the Lights On) to keep kits safe and available.
Putting it into practice
Start with accurate current estimates. Choose DC-rated devices that clear faults within cable limits. Grade protection from the PV strings through the battery and inverter. Validate with tests, then document settings and wiring. This creates portable solar systems that handle faults gracefully and protect users and equipment.
FAQ
Do I need fuses on each PV string in a small portable array?
If two strings are in parallel, backfeed into a faulted string can be limited. Many codes ask for string fuses once you have three or more parallel strings. For compact kits, assess backfeed, controller ratings, and cable ampacity, then decide. Non-legal advice.
Can I use an AC breaker on a 24–48 V DC battery circuit?
No. AC-only breakers are not designed to break DC arcs. Use devices listed for DC at or above your system voltage and check the breaking capacity.
How do I size the battery main breaker?
Sum the maximum continuous DC load, include surge, and ensure the breaker holds through normal inrush. Then verify it clears a battery short within safe energy for the cable and within the BMS cutoff. Select a DC MCCB or fuse with adequate DC rating.
Do grid-forming inverters remove the need for fuses?
No. Grid-forming improves stability and restoration, but fault current is still limited. You still need selective OCPD on PV, battery, DC bus, and AC outputs, as large labs and agencies note in Grid Codes for Renewable Powered Systems and the DOE Success Story.
Should I add surge protection and RCD/GFCI?
Yes. Use DC surge protective devices on the PV side and RCD/GFCI for AC outlets. Grade settings to avoid nuisance trips while keeping solar panel safety high. Non-legal advice.
Disclaimer: Technical content is for information only and does not replace local codes or professional engineering. Non-legal advice.
