Anern 3.5 kw solar inverter

3.5KW Pure Sine Wave Solar Inverter

by Anern

Description:

·Pure sine wave inverter.

·Built-in MPPT solar controller.

·Inverter running without battery.

·Configurable AC / Solar charger priority via LCD setting.

Package Content:

1 x The Unit,1 x User Manual,1 x DC Fuse,1 x Ring Terminal,1 x Strain Relief Plate,1 x PV Wire Cover,4 x Screws

The shipping cost and product prices are for reference only, pls leave your demands and contact information, we will send you the quotation soon.

For wholesale business or project, pls email: Cooperation@anern.com

Sold out
$301.00 - $326.83
$326.83
$301.00 - $326.83
$326.83
AN-SCI02-PLUS-3500W: With WiFi module

Video of 3.5KW Pure Sine Wave Solar Inverter



Specification of 3.5KW Pure Sine Wave Solar Inverter

Model

SCI02-PLUS-3500

RATED POWER

3500W

INPUT

Voltage

230 VAC

Selectable Voltage Range

170-280 VAC (For Personal Computers)

90-280 VAC (For Home Appliances)

Frequency Range

50 Hz/60 Hz (Auto sensing)

OUTPUT

AC Voltage Regulation (Batt. Mode)

230VAC ± 5%

Surge Power

7000VA

Efficiency (Peak) PV to INV.

97%

Efficiency (Peak) Battery to INV.

94%

Transfer Time

10 ms (For Personal Computers) ; 20 ms (For Home Appliances)

Waveform

Pure sine wave

BATTERY & AC CHARGER

Battery Voltage

24 VDC

Floating Charge Voltage

27 VDC

Overcharge Protection

33 VDC

SOLAR CHARGER

Maximum PV Array Power

5000 W

MPPT Range @ Operating Voltage

120 ~ 500 VDC

Maximum PV Array Open Circuit Voltage

500 VDC

Maximum Charging Current

100A

Maximum Efficiency

98%

PHYSICAL
Dimension 100 x 300 x 440mm
Net Weight (kgs) 9
Communication interface RS232/WIFI

Package Dimension

Gross Weight

62*42*25cm

12.3kg



Key Features of 3.5KW Pure Sine Wave Solar Inverter

  • Pure sine wave inverter.
  • Built-in MPPT solar controller.
  • Inverter running without battery.
  • Configurable input voltage rang for home appliances and personal computers via LCD setting.
  • Configurable battery charging current based on applications via LCD setting.
  • Configurable AC / Solar charger priority via LCD setting.



3.5 KW Solar Inverter Description

The 3.5KW solar inverter is a versatile and powerful solar power solution for residential and commercial applications. Utilizing advanced technology, it provides seamless integration between photovoltaics and loads, ensuring high performance and extended longevity.

Powerful, efficient and reliable. The 3.5 kw solar inverter is perfect for your home backup power needs with 3.5KW of continuous output power. Do solar inverter online shopping now!

Application of 3.5KW Pure Sine Wave Solar Inverter

A solar inverter is one of the most crucial elements of any solar energy system. Anern solar inverter allows the conversion of direct current (DC) into alternating current (AC), thus making the energy usable for a wide variety of residential, commercial as well as industrial applications such as powering various instruments ranging from commercial and regular home appliances like refrigerators, TVs and microwaves to huge industrial equipment.

Anern 3.5 kw solar inverter high qualityAnern solar inverter online shopping

★★★★★
★★★★★
★★★★★
★★★★★
