25.6v 51.2V 100AH 200AH 280AH Wall-Mounted Solar LiFePo4 Lithium Ion Battery Energy Storage Battery

by Anern

Description:

◆ Long service life over 8 years;
◆ Modular design, small size and light weight;
◆ One key switch machine, the operation is more convenient;
◆ Suitable for long-term charge and discharge cycles;
◆ Adopt multi-level energy consumption management;
◆ Multiple parallel machines, automatic address acquisition without manual operation;
◆ Support high-current charging and discharging;
◆ Front operation and fornt wiring are convenient for installation and maintenance;
◆ Adopt high-performance processor, international brand devices, high reliability;
◆ Multiple communication interfaces: RS485, RS232, CAN;
◆ Highly compatible BMS, seamless connection with energy storage inverter;
◆ Perfectly compatible with our inverter;
◆ Safety certification: CE, ROHS, UN38.3, MSDS, etc.

Package Content:

1 x The Unit,1 x Mounting Brackets,1 x Bag of Screws,1 x User Manual

The shipping cost and product prices are for reference only, pls leave your demands and contact information, we will send you the quotation soon.

For wholesale business or project, pls email: Cooperation@anern.com

Original price $483.00 - Original price $2,188.00
Original price
$483.00
$483.00 - $2,188.00
Current price $483.00
AN-LPB-N: 25.6v 100ah



Anern 5kwh battery price of bulk order



Video of 25.6v 51.2V 100AH 200AH 280AH Wall-Mounted Solar LiFePo4 Lithium Ion Battery Energy Storage Battery



Key Features of 25.6v 51.2V 100AH 200AH 280AH Wall-Mounted Solar LiFePo4 Lithium Ion Battery Energy Storage Battery

  • Each module is equipped with an independent BMS system.
  • Safe lithium iron phosphate battery cell.
  • Longer cycle life>6000 cycles, 20 years design life.
  • Standard design with helpful pulling ear quick stacking.



Specification of 25.6v 51.2V 100AH 200AH 280AH Wall-Mounted Solar LiFePo4 Lithium Ion Battery Energy Storage Battery

Model

AN-LPB-N-24100

AN-LPB-N-24200

AN-LPB-N-48100

AN-LPB-N-48200

AN-LPB-N-48280
(Floor type)

Battery Type

LiFePO4

Typical Capacity(AH)

100AH

200AH

100AH

200AH

280AH

Typical Voltage(V)

25.6V

25.6V

51.2V

51.2V

51.2V

Energy storage(Kwh)

2.56Kwh

5.12Kwh

5.12Kwh

10.24Kwh

14.33Kwh

Voltage Working Range(V)

22.4-29.2V

22.4-29.2V

44.8-58.4V

44.8-58.4V

44.8-58.4V

Working Temperature(°C)

Charge: 0-+55°C
Discharge: -20-+60°C

Storage Temperature(°C)

-20-+40°C

Standard Charge Current(A)

0.5C

Max. Charge Current(A)

100A

100A

100A

200A

200A

Max. Discharge Current(A)

100A

100A

100A

200A

200A

SOC Accuracy

<8%

Dimension(mm)

410*370*160mm

570*410*160mm

570*410*160mm

860*485*160mm

455*350*810mm

Weight(kg)

28kg

45kg

45kg

89kg

120kg

IP Grade

IP54

Cooling

Nature

Communication

RS232, RS485, CAN

Certifications

 CE, ROHS, UN38.3, MSDS



Application of 25.6v 51.2V 100AH 200AH 280AH Wall-Mounted Solar LiFePo4 Lithium Ion Battery Energy Storage Battery

Anern wall-mounted batteries have been specifically designed for true deep cycle, long service life capability in adverse temperatures and handling conditions. As part of your off grid solar energy system- energy storage to power all electrical loads for residences, businesses, villages, and remote operations.

★★★★★
★★★★★
★★★★★
★★★★★
